General Description
BD Series Pleated Filter Cartridge is constructed of hydrophilic PTFE membrane which has excellent chemical compatibility and corrosion resistance.The membrane is hydrophilic which can filter the liquid directly without pre-wetting to save the operation time.
Features
Hydrophilic membrane without pre-wetting
The membrane is hydrophilic which can filter the liquid directly without pre-wetting to save the operation time.
Excellent chemical compatibility
PTFE membrane got excellent chemical compatibility.It has good tolerance to various chemical and can be used for filtering kinds of corrosive liquids.
Absolute filtration efficiency
PTFE membrane provide high filtration efficiency with absolute micron rating make sure to
reduce the particals.
100% integrity tested
Specifications
| Removal ratings | 0.1um,0.22um,0.45um |
| Length | 40'' |
| Outside diameter | 69mm |
| Maximum operating temperature | 80°C |
| Maximum operating differential pressure | 4.0 bar |
| Maximum operating differential pressure (reverse direction) | 4 bar@ 21ºC 2.4 bar@ 80ºC |
| Sterilization temperature time | 5 times, 20 Minute cycles at 120ºC |
Applications
Filtration of strong causticity liquid
Filtration of strong oxidizing property liquid
Filtration of ultra pure microelectronic chemicals
Sterile filtration of pharmaceutical chemicals
Order Information
For example:
BD0.45M40EP
Rating:0.45um, 222/Flat End, Length: 40",seal material:EPDM;PP core
